Eyepiece | Standard Configuration | Auxiliary objective 0.5X | Auxiliary objective 2X | |||
Working distance 115mm | Working distance 211mm | Working distance 43.5mm | ||||
Magnification | Field of view | Magnification | Field of view | Magnification | Field of view | |
10X/22mm | 8X | 27.5 | 4X | 55.0 | 16X | 13.8 |
50X | 4.4 | 25X | 8.8 | 100X | 2.2 | |
15X/16mm | 12X | 20.0 | 6X | 40.0 | 24X | 10.0 |
75X | 3.2 | 37.5X | 6.4 | 150X | 1.6 | |
20X/12mm | 16X | 15.6 | 8X | 31.2 | 32X | 7.8 |
100X | 2.5 | 50X | 5.0 | 200X | 1.3 | |
25X/9mm | 20X | 11.3 | 10X | 22.5 | 40X | 5.6 |
125X | 1.8 | 62.5X | 3.6 | 250X | 0.9 | |
30X/8mm | 24X | 10.0 | 12X | 20.0 | 48X | 5.0 |
150X | 1.6 | 75X | 3.2 | 300X | 0.8 | |
Magnification | Standard configuration: 8X-50X, optional eyepiece and auxiliary objective lens can be extended to 4X-300X, continuous zoom | |||||
Eyepiece | Standard configuration: 10X/22mm, large field flat eyepiece, adjustable diopter | |||||
Optional eyepiece | 10X/22mm，15X/16mm，20X/12mm，25X/9mm，30X/8mm | |||||
Observation head | 45° tilt, 360° rotation, interpupillary distance adjustment range 52-75mm, bilateral diopter adjustment ±5 | |||||
Hinged trinocular head | ||||||
Objective | 0.8X-5.0X continuous zoom, objective zoom ratio 6.3:1 to ensure image plane parfocality | |||||
Auxiliary objective | Optional 0.5X, 2.0X | |||||
Focus bracket | Vertical arm focusing bracket, hand wheel with adjustable tightness, lifting range 104mm | |||||
Base | S7 vertical arm base, other bases can be selected, see the base attachment for details | |||||
illumination | Reflected lighting, transmitted lighting 100V-240V, LED, optional various fluorescent, LED ring lights | |||||
